Helix Engineers is a manufacturer and supplier of Stainless Steel Hand Pallet Trucks in Ahmedabad, Gujarat, India. Our SS Hand Pallet Truck Model HE-05 is designed for lifting, handling and transporting palletized materials in industrial and commercial environments where stainless steel construction is required.
With a load capacity of 2500 kg, this manually operated pallet truck features a heavy-duty SS-304 stainless steel structure, 1150 mm fork length, 550 mm overall fork width and nylon wheels for smooth movement on suitable floors.
The stainless steel construction makes this model a suitable option for applications where corrosion resistance, cleanability and material compatibility are important considerations. The manual hydraulic lifting system helps operators raise and lower palletized loads for short-distance material movement.
Helix Engineers offers industrial material handling solutions for factories, warehouses, production units and other facilities across India, with customization discussions available according to application requirements.
SS Hand Pallet Truck HE-05 – Technical Specifications
- Product Name SS Hand Pallet Truck
- Model Number HE-05
- Manufacturer Helix Engineers
- Rated Capacity 2500 kg
- Material of Construction SS-304 stainless steel
- Main Structure Heavy-duty SS-304 C-section and tie-rod plate
- Plate Thickness 4 mm, as specified
- Fork Length 1150 mm
- Overall Fork Width 550 mm
- Single Fork Width 160 mm
- Minimum Fork Height 90 mm
- Maximum Fork Height 200 mm
- Lifting Travel 110 mm
- Steering Wheels Ø180 × 50 mm – 2 Nos.
- Tandem Load Wheels Ø80 × 70 mm – 4 Nos.
- Wheel Material Nylon
The Helix Engineers SS Hand Pallet Truck HE-05 can be considered for:
- Moving palletized raw materials and finished goods.
- Transporting stainless steel-compatible packaged products.
- Internal material movement in production areas.
- Loading and unloading compatible pallets.
- Moving containers, cartons and industrial supplies.
- Material handling in cleanable or corrosion-conscious environments.
- Industries That May Benefit
- Food and beverage processing.
- Pharmaceutical manufacturing.
- Chemical and specialty chemical facilities.
- Cosmetics and personal care manufacturing.
- Packaging and FMCG industries.
- Stainless steel fabrication and engineering.
- Warehouses and distribution centres.
- Industrial production and assembly units.
